SLTBLDC-1124C-5
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
Product parameters
| Rated Voltage | DC 24V |
| Operating Voltage Range | 16–32 VDC |
| Rated Current | ≤6.0 A |
| Rated Speed | 3200 ±50 rpm |
| Minimum Speed | 1000 ±50 rpm |
| Noise Level | ≤78 dB(A) |
| Static Pressure | 100 Pa |
| Airflow | ≥1300 m³/h |
| Ambient Operating Temperature | -40℃ to +120℃ |
| Fan Insulation Resistance | >20 MΩ (under normal conditions) |
| Ingress Protection Rating | IP68 |
| Service Life | ≥40,000 hours (depending on operating conditions) |
| Weight | 2.0 kg ±5% |
Specification
Built for High-Duty Operation
Engineered to handle continuous workloads with consistent airflow, making it reliable for demanding mobile and power-intensive systems.
Stable Performance Across Harsh Conditions
Maintains operational stability despite temperature variation, moisture exposure, and mechanical stress.
Efficient Airflow with Controlled Energy Use
Optimized motor design supports strong air movement while helping reduce overall system power consumption.
Low Mechanical Wear, Longer Service Life
Brushless architecture minimizes friction and component fatigue, lowering maintenance frequency over time.
Smart System Integration Ready
Supports system monitoring and control, enabling easier integration into modern electronic and thermal management platforms.
Mobile Heavy-Duty Equipment
Delivers reliable airflow for engineering vehicles, construction machinery, and other demanding mobile platforms.
Commercial & Passenger Vehicles
Enhances thermal management in buses, vans, and fleet vehicles, supporting consistent climate control and system efficiency.
Electric Vehicle Charging Stations
Optimizes cooling for EV charging modules and power electronics, maintaining performance under continuous operation.
Industrial & Energy Systems
Integrates seamlessly into power management and thermal control setups, ensuring stable operation in high-load environments.
Custom Thermal Solutions
Flexible design allows incorporation into OEM and bespoke systems requiring precision airflow and dependable reliability.
Check Airflow Alignment
Ensure the fan is positioned correctly for optimal cooling and balanced thermal circulation.
Maintain Adequate Clearance
Keep space around intake and exhaust to prevent airflow blockage and performance loss.
Use Vibration-Resistant Mounting
Secure installation reduces noise and enhances reliability in mobile and industrial applications.
Verify Electrical Compatibility
Match the fan with your system’s power and control setup for smooth operation and long-term stability.
Protect Against Environmental Stress
Shield from dust, moisture, and contaminants to maintain efficiency and extend operational life.
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
Ordering Information
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
Q1: What makes this fan reliable for continuous operation?
A: Its brushless design reduces wear and heat buildup, ensuring stable airflow and consistent performance for long-running systems.
Q2: Can this fan adapt to varying environmental conditions?
A: Yes, it maintains efficiency under vibration, moisture, and temperature fluctuations, making it suitable for diverse operational environments.
Q3: Is this fan compatible with multiple vehicle and energy applications?
A: Absolutely. It integrates seamlessly with engineering vehicles, commercial fleets, and EV charging infrastructure, supporting advanced thermal management.
Q4: How does the fan contribute to system efficiency?
A: By providing precise airflow control and stable operation, it optimizes heat dissipation while reducing unnecessary energy consumption.
Q5: Does it support system monitoring or control feedback?
A: Yes, it can provide feedback signals that allow integration with electronic controllers for real-time performance monitoring.
Q6: Is this fan suitable for custom or OEM projects?
A: Its flexible design allows easy integration into bespoke cooling, heating, or thermal management solutions across various industries.
