SLT1624C/X-W10
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
| Max Fan Speed | 3000rpm |
| Min Fan Speed | 1000rpm |
| Weight | 2.4KG |
| Operating supply voltage rang | 24V |
| Operating working temperature range | -40°C - 85°C |
| Storage temperature range |  -40°C - 100°C |
| Life time | up to 8000 hours depending on missing profile |
| Static presusure Pa | Airflow m3/h | Current A |
| 0 | 3450 | 12.2 |
| 20 | 3300 | 12.4 |
| 40 | 3160 | 12.6 |
| 60 | 3010 | 12.6 |
| 80 | 2850 | 12.5 |
| 100 | 2660 | 12.6 |
| 120 | 2500 | 12.5 |
| 140 | 2326 | 12.4 |
| 160 | 2111 | 12.3 |
| 180 | 1824 | 12.1 |
| 200 | 1635 | 12 |
The grey line is Airflow
Large Diameter & High Airflow – The 16″ (~406 mm) size combined with up to ~3000 rpm allows for powerful air delivery, supporting condensers or radiators where large volume cooling is required.
Robust Design with IP68 Protection – With an IP68 rating, the fan can handle dust, dirt and water ingress — ideal for heavy-duty and outdoor use.
Wide Temperature Range & Long Life – Operates reliably from -40 °C to +85 °C, with a lifetime up to 8000 hours under proper conditions.
Drop-In Replacement & Compatibility – Designed to replace the standard Spal-style fans in 24 V systems, making retrofit or OEM integration easier.
Versatile Application Scope – Suitable for vehicles (trucks/buses), electric/hybrid vehicles, industrial machines (e.g., excavators, loaders, snow ploughs), and refrigeration transport.
Customizable Options – Cable lengths, connectors, mounting brackets, airflow direction (puller/pusher) can be tailored to your requirements.
This fan is ideally suited for:
Heavy-duty trucks and buses’ condenser / radiator cooling systems
Electric and hybrid vehicles with 24 V cooling circuits
Construction machinery, loaders, excavators, snow-plough equipment
Forestry and agricultural equipment requiring high-capacity cooling
Refrigeration trucks / cold-chain logistics vehicles
Any large-scale industrial cooling scenario where high airflow and reliability are critical
IATF I16949:2016 Certificate
IATF 16949:2016 Certificate
EMC Certificate
CE certificate
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
Q1: What makes this fan a good replacement for SPAL models?
A: The SLT1624C/X-W10 shares the same 16-inch size and 24V operating voltage as many SPAL axial fans, with similar airflow performance and mounting dimensions. It offers reliable performance at a more cost-effective price.
Q2: Can this fan operate continuously for long hours?
A: Yes. It is designed for industrial and automotive systems that require long continuous operation, thanks to its robust brushed DC motor and high-temperature bearings rated up to 85°C.
Q3: Is this fan waterproof and dustproof?
A: Yes. The fan is IP68-rated, ensuring full protection against dust ingress and long-term water immersion, making it suitable for outdoor and off-road applications.
Q4: Does this fan generate a lot of noise?
A: The SLT1624C/X-W10 is engineered with balanced blades and vibration-reduction design to minimize noise and ensure smooth operation, even under high load.
Q5: What kind of maintenance does this brushed fan require?
A: Periodically check and clean the blades to remove dust buildup. Avoid oil contamination near the motor brushes and ensure proper ventilation to extend service life.
Q6: Can I request a custom connector or bracket design?
A: Absolutely. We can provide custom connectors (AMP, Delphi, waterproof plugs, etc.), different wire lengths, and optional brackets to fit your cooling system layout.
