SLT-31024
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
Product Parameters
| Rated Voltage | 24V |
| Rated Current | ≤6A |
| Rated Speed | 3800rpm |
| Airflow | ≥600m³/h |
| Noise | ≤74dB(A) |
| Service Life | 8000h |
| Ambient Temperature | -40~-+75℃ |
| Overall Balance | ≤40mg |
Specification
Stable brushed motor architecture delivers consistent airflow under frequent start-stop conditions, making it well-suited for long-hour thermal cycles in HVAC and heating systems.
Optimized evaporative airflow design enhances heat transfer efficiency, helping cooling and heating units respond faster to temperature changes.
Strong tolerance to voltage fluctuation ensures dependable performance in mobile, industrial, and energy-related equipment environments.
Compact yet robust construction allows easy integration into space-limited air conditioning modules and auxiliary heating assemblies.
Proven durability for continuous operation, reducing maintenance frequency and supporting reliable system uptime across diverse thermal applications.
Sunlight evaporative cooling fans provide low-cost, energy-efficient cooling for large, open, or high-temperature spaces where traditional air conditioning is ineffective or expensive.
They are widely used in industrial factories, warehouses, commercial buildings, agricultural facilities, and semi-open or outdoor areas such as workshops, loading docks, farms, and event spaces.
Designed for hot and dry climates—including the Middle East, Southeast Asia, Africa, Australia, and southern USA—Sunlight fans deliver powerful airflow, fresh air circulation, and reduced operating costs.
Install in open or well-ventilated areas to ensure proper airflow and maximum cooling efficiency. Avoid enclosed spaces where air circulation is limited.
Position the fan facing the main heat source or working area to deliver effective evaporative cooling across large spaces.
Ensure a stable water supply and clean water quality, especially in hot and dry regions, to maintain consistent cooling performance and prevent scale buildup.
Allow sufficient clearance around the air inlet and outlet to avoid airflow blockage and reduce energy consumption.
Use evaporative cooling fans in hot and dry climates, such as the Middle East, Southeast Asia, Africa, Australia, and southern USA, where cooling efficiency is highest.
Clean cooling pads and filters regularly to maintain airflow, improve cooling effectiveness, and extend service life.
Shut down and drain water during long periods of non-use to prevent corrosion and ensure reliable operation.
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
1. How effective are evaporative cooling fans in hot climates?
Evaporative cooling fans perform best in hot and dry regions such as the Middle East, Africa, Australia, Southeast Asia, and southern USA, delivering noticeable temperature reduction with much lower energy consumption than air conditioning.
2. Can this evaporative fan be used in large or semi-open spaces?
Yes. Sunlight evaporative fans are specifically designed for large areas, high ceilings, and semi-open environments like factories, warehouses, workshops, and loading bays where traditional AC systems are inefficient.
3. How much energy can an evaporative cooling fan save compared to air conditioning?
Evaporative cooling fans typically consume up to 70–80% less electricity than conventional air conditioners, helping reduce operating costs while maintaining continuous airflow and fresh air circulation.
4. What water quality is required for stable operation?
Clean or filtered water is recommended, especially in hot and dusty regions, to prevent scale buildup, protect cooling pads, and ensure consistent cooling performance over long-term use.
5. Is regular maintenance required for evaporative cooling fans?
Maintenance is simple. Regular cleaning of cooling pads, filters, and the water system helps maintain airflow efficiency, extend service life, and ensure reliable performance in industrial and commercial applications.
Product Parameters
| Rated Voltage | 24V |
| Rated Current | ≤6A |
| Rated Speed | 3800rpm |
| Airflow | ≥600m³/h |
| Noise | ≤74dB(A) |
| Service Life | 8000h |
| Ambient Temperature | -40~-+75℃ |
| Overall Balance | ≤40mg |
Specification
Stable brushed motor architecture delivers consistent airflow under frequent start-stop conditions, making it well-suited for long-hour thermal cycles in HVAC and heating systems.
Optimized evaporative airflow design enhances heat transfer efficiency, helping cooling and heating units respond faster to temperature changes.
Strong tolerance to voltage fluctuation ensures dependable performance in mobile, industrial, and energy-related equipment environments.
Compact yet robust construction allows easy integration into space-limited air conditioning modules and auxiliary heating assemblies.
Proven durability for continuous operation, reducing maintenance frequency and supporting reliable system uptime across diverse thermal applications.
Sunlight evaporative cooling fans provide low-cost, energy-efficient cooling for large, open, or high-temperature spaces where traditional air conditioning is ineffective or expensive.
They are widely used in industrial factories, warehouses, commercial buildings, agricultural facilities, and semi-open or outdoor areas such as workshops, loading docks, farms, and event spaces.
Designed for hot and dry climates—including the Middle East, Southeast Asia, Africa, Australia, and southern USA—Sunlight fans deliver powerful airflow, fresh air circulation, and reduced operating costs.
Install in open or well-ventilated areas to ensure proper airflow and maximum cooling efficiency. Avoid enclosed spaces where air circulation is limited.
Position the fan facing the main heat source or working area to deliver effective evaporative cooling across large spaces.
Ensure a stable water supply and clean water quality, especially in hot and dry regions, to maintain consistent cooling performance and prevent scale buildup.
Allow sufficient clearance around the air inlet and outlet to avoid airflow blockage and reduce energy consumption.
Use evaporative cooling fans in hot and dry climates, such as the Middle East, Southeast Asia, Africa, Australia, and southern USA, where cooling efficiency is highest.
Clean cooling pads and filters regularly to maintain airflow, improve cooling effectiveness, and extend service life.
Shut down and drain water during long periods of non-use to prevent corrosion and ensure reliable operation.
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
1. How effective are evaporative cooling fans in hot climates?
Evaporative cooling fans perform best in hot and dry regions such as the Middle East, Africa, Australia, Southeast Asia, and southern USA, delivering noticeable temperature reduction with much lower energy consumption than air conditioning.
2. Can this evaporative fan be used in large or semi-open spaces?
Yes. Sunlight evaporative fans are specifically designed for large areas, high ceilings, and semi-open environments like factories, warehouses, workshops, and loading bays where traditional AC systems are inefficient.
3. How much energy can an evaporative cooling fan save compared to air conditioning?
Evaporative cooling fans typically consume up to 70–80% less electricity than conventional air conditioners, helping reduce operating costs while maintaining continuous airflow and fresh air circulation.
4. What water quality is required for stable operation?
Clean or filtered water is recommended, especially in hot and dusty regions, to prevent scale buildup, protect cooling pads, and ensure consistent cooling performance over long-term use.
5. Is regular maintenance required for evaporative cooling fans?
Maintenance is simple. Regular cleaning of cooling pads, filters, and the water system helps maintain airflow efficiency, extend service life, and ensure reliable performance in industrial and commercial applications.
