WBLB-AS1350-B
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
Product parameters
| Rated Voltage | DC 12V |
| Voltage Range | DC 9.0V – 16.0V |
| Rated Current | <25A |
| Maximum Airflow | 1100 m³/h ±150 m³/h @ 0 Pa |
| Rated Speed | 3350 rpm ±150 rpm |
| Noise Level | ≤80 dB(A) @ 1m (measured at fan side) |
| Fan Lifetime | ≥25,000 h |
| Waterproof Rating | IP68 |
| Operating Temperature | -40°C to +95°C |
| Humidity | Maximum 95% |
| Insulation Resistance | ≥20 MΩ (at room temperature) |
| Net Weight | 2.7 kg |
| Vibration Resistance | 20 ms, 5g |
Specification
Powerful and Efficient
Delivers stable airflow at 12V 340W, optimizing cooling and heating performance with minimal energy consumption.
Versatile Thermal Support
Excels in HVAC, heaters, and evaporative cooling systems, adapting to varied temperature management needs.
Durable Brushless Design
Reduces maintenance and extends operational life under continuous or heavy-duty usage.
Precision Performance
Consistent airflow ensures even temperature distribution, improving system efficiency and user comfort.
Compact Yet Robust
Slim form factor allows integration in constrained spaces without compromising power or reliability.
Applications
Evaporative Cooling Systems
Designed for high-efficiency evaporative air coolers, delivering stable airflow and consistent performance in continuous-duty cooling environments.
Air Conditioning (Cooling & Heating Units)
Widely used in AC systems for both cooling and heating modes, supporting heat exchange, airflow circulation, and overall system efficiency.
Electric & Industrial Heaters
Ideal for forced-air heaters, helping distribute warm air evenly while maintaining reliable operation under elevated temperatures.
HVAC Ventilation Equipment
Suitable for residential, commercial, and light industrial HVAC systems where quiet operation, durability, and precise airflow control are required.
Thermal Management Modules
Applied in integrated thermal solutions to regulate temperature in enclosed systems, improving component lifespan and operational stability.
Verify Airflow Direction Before Installation
Correct airflow orientation is essential to achieve optimal cooling or heating efficiency.
Maintain Proper Air Clearance
Ensure unobstructed air intake and exhaust to prevent performance loss and overheating.
Use Stable, Vibration-Resistant Mounting
Secure installation reduces noise, improves reliability, and extends fan service life.
Match Power and Control Specifications
Proper power supply and control compatibility ensure smooth operation and system stability.
Position Strategically in Thermal Systems
Ideal placement enhances heat exchange efficiency in cooling, heating, and HVAC applications.
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
FAQ
Q1: What makes this brushless evaporative fan suitable for long-term operation?
A: The brushless motor design reduces mechanical wear and heat buildup, allowing the fan to run continuously with stable airflow and minimal maintenance requirements.
Q2: Can this fan operate reliably in harsh or demanding environments?
A: Yes. It is built to withstand moisture, vibration, and wide temperature variations, making it suitable for both indoor and semi-outdoor thermal applications.
Q3: Is the WBLB-AS1350-B compatible with both cooling and heating systems?
A: Absolutely. The fan supports efficient air movement in cooling, heating, and combined HVAC systems, helping maintain balanced thermal performance year-round.
Q4: How does this fan help improve overall system efficiency?
A: By delivering consistent airflow and precise speed control, it enhances heat exchange efficiency while reducing unnecessary energy loss.
Q5: Does the fan provide any operational feedback for system monitoring?
A: Yes. The fan outputs a stable signal that allows system controllers to monitor operating status and optimize performance in real time.
Q6: Is this model suitable for customized or OEM system designs?
A: The compact structure and flexible integration make it ideal for customized evaporative cooling, air conditioning, heating equipment, and other thermal management solutions.
