The SLT1024C-W10 is a universal 10-inch (≈ 254 mm) radiator cooling fan engineered for high performance in demanding conditions. Powered by 24 V DC and rated at 150 W, it is designed for pusher configurations (blow) to suit diverse cooling system layouts. With a fully sealed structure (IP68) and a durable motor, this fan offers long service life, stable performance in extreme temperatures, and minimal maintenance needs.
SLT1024C-W10
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
| Noise | 70dB(A) |
| IP | IP68 |
| Weight | 1.4KG |
| Operating supply voltage rang | 24V |
| Operating working temperature range | -40°C - 85°C |
| Storage temperature range |  -40°C - 100°C |
| Life time | up to 2400 hours depending on missing profile |
Dual Direction Operation: Easily switches between push and pull modes by reversing polarity.
High Airflow & Cooling Efficiency: Optimized blade pitch and aerodynamic design deliver strong, consistent airflow.
Sealed & Rugged Design: Rated IP68 against dust and strong water jets; suitable for outdoor and harsh environments.
Low Noise: Operates at ≤ 70 dB(A) for quieter performance.
Wide Temperature Range: Works reliably between –40 °C and +85 °C.
Long Working Life: Up to ~2400 hours under rated conditions.
Universal Compatibility: Suitable for trucks, agricultural machinery, refrigeration units, and specialty vehicles.
This universal 10-inch fan is well suited for:
Car / truck radiators and engine cooling
Construction, mining, and heavy machinery
Agricultural equipment
Refrigerated transport and cold chain units
Snow removal / winter equipment
Specialty vehicles, forestry, engineering machines
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
IATF I16949:2016 Certificate
IATF 16949:2016 Certificate
EMC Certificate
CE certificate
Name1
Name2
Name3
Name4
Name5
Name1
Name2
Name3
Name4
Name5
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
Q1: How can I determine whether to install this fan as a pusher or puller?
A1: The direction depends on your radiator’s layout. If mounted in front of the radiator, use it as a pusher; if installed behind, set it as a puller. The airflow direction is indicated by arrows on the housing.
Q2: Does this fan require any special maintenance?
A2: No special maintenance is needed. Just keep the blades and grille clean from debris and ensure the electrical connectors are properly insulated from moisture.
Q3: What materials are used for the fan blades and housing?
A3: The blades and housing are made of high-strength, heat-resistant reinforced plastic to provide durability, corrosion resistance, and stable performance in high-temperature environments.
Q4: Can the fan be connected to a PWM controller for speed adjustment?
A4: This model supports fixed-speed operation. However, customized versions can be produced to support PWM or variable-speed control upon request.
Q5: What kind of warranty do you offer for this product?
A5: We provide a 12-month warranty against manufacturing defects under normal operating conditions. Technical support and replacement services are available during the warranty period.
