SLTBLDC-1112C-5
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
Product parameters
| Rated Voltage | DC 12V |
| Operating Voltage Range | 9-16 VDC |
| Rated Current | ≤12.0 A |
| Rated Speed | 3200 ±50 rpm |
| Minimum Speed | 1000 ±50 rpm |
| Noise Level | ≤78 dB(A) |
| Static Pressure | 100 Pa |
| Airflow | ≥1300 m³/h |
| Ambient Operating Temperature | -40℃ to +120℃ |
| Fan Insulation Resistance | >20 MΩ (under normal conditions) |
| Ingress Protection Rating | IP68 |
| Service Life | ≥40,000 hours (depending on operating conditions) |
| Weight | 2.0 kg ±5% |
Specification
Built for High-Duty Operation
Engineered to handle continuous workloads with consistent airflow, making it reliable for demanding mobile and power-intensive systems.
Stable Performance Across Harsh Conditions
Maintains operational stability despite temperature variation, moisture exposure, and mechanical stress.
Efficient Airflow with Controlled Energy Use
Optimized motor design supports strong air movement while helping reduce overall system power consumption.
Low Mechanical Wear, Longer Service Life
Brushless architecture minimizes friction and component fatigue, lowering maintenance frequency over time.
Smart System Integration Ready
Supports system monitoring and control, enabling easier integration into modern electronic and thermal management platforms.
The brushless DC fan is ideal for large buses, coaches, and commercial vehicles, delivering efficient, reliable cooling for vehicle HVAC systems and engine compartments.
It is widely used in:
Passenger buses & coaches – Maintain cabin comfort and air quality in hot and humid climates.
Commercial trucks & delivery vehicles – Protect engines and electronics from overheating during long-distance operation.
Electric and hybrid buses – Provide precise cooling for batteries, inverters, and power electronics.
Shuttle buses & airport transport vehicles – Ensure stable airflow and low-noise operation for passenger comfort.
Designed for global markets, including North America, Europe, Southeast Asia, the Middle East, and Australia, it provides high-efficiency cooling, long service life, and low maintenance, even in high-temperature, demanding conditions.
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
Q1: What makes this fan reliable for continuous operation?
A: Its brushless design reduces wear and heat buildup, ensuring stable airflow and consistent performance for long-running systems.
Q2: Can this fan adapt to varying environmental conditions?
A: Yes, it maintains efficiency under vibration, moisture, and temperature fluctuations, making it suitable for diverse operational environments.
Q3: Is this fan compatible with multiple vehicle and energy applications?
A: Absolutely. It integrates seamlessly with engineering vehicles, commercial fleets, and EV charging infrastructure, supporting advanced thermal management.
Q4: How does the fan contribute to system efficiency?
A: By providing precise airflow control and stable operation, it optimizes heat dissipation while reducing unnecessary energy consumption.
Q5: Does it support system monitoring or control feedback?
A: Yes, it can provide feedback signals that allow integration with electronic controllers for real-time performance monitoring.
Q6: Is this fan suitable for custom or OEM projects?
A: Its flexible design allows easy integration into bespoke cooling, heating, or thermal management solutions across various industries.
