SLT-0912X-W10-T
Sunlight
| Quantity: | |
|---|---|
Product parameters
| Rated voltage | DC 12 V |
| Load current | ≤9 A |
| Rated speed | 3200 rpm ±150 rpm |
| Static pressure | 0 Pa |
| Motor power | 100 W |
| Airflow | 1200 m³/h ±50 m³/h |
| Noise | ≤70 dB(A) |
| Protection rating | IP67 |
| Duty type | S1 |
| Service life | ≥4500 h |
| Weight | 1.6 kg ±5 % |
| Operating ambient temperature | –40 °C to +85 °C |
Specification
Compact Design for Tight Spaces – Ultra-slim profile fits engineering vehicles, commercial buses, and EV charging stations, ideal for space-limited applications.
Reliable Thermal Management – Provides consistent airflow to prevent overheating of engines, batteries, and electronic modules in harsh conditions.
Low Noise Operation – Optimized for quiet performance in operator cabins, passenger vehicles, and indoor charging environments.
Durable & Long-Lasting – High-quality brushed motor ensures stable performance under continuous use and vibration-prone industrial or mobile applications.
Versatile Applications – Suitable for construction machinery, trucks, buses, EV chargers, and compact industrial systems, covering a wide range of vehicle and equipment cooling needs.
Global Compatibility – Designed for North America, Europe, Southeast Asia, and the Middle East, ensuring reliable operation in diverse climates.
Easy Installation & Maintenance – Lightweight and compact for quick integration into vehicles, cabinets, and industrial equipment, saving space and labor.
The SLT-0912X-W10-T brushed DC fan is designed for compact spaces in both mobile and stationary systems. It provides reliable cooling and airflow management for:
Construction & Engineering Vehicles – Efficiently cools electronic modules, control units, and onboard power systems in harsh and vibration-prone environments.
Commercial Buses & Trucks – Supports thermal management for HVAC systems, batteries, and auxiliary electronics.
EV Charging Stations & Power Cabinets – Maintains stable temperature for power modules and sensitive electronic components.
Industrial Equipment & Control Panels – Perfect for compact enclosures requiring continuous cooling and low-noise operation.
Built for global applications, including North America, Europe, Southeast Asia, and the Middle East, this fan ensures consistent performance in diverse climates and demanding conditions.
Optimal Orientation – Install the fan with the airflow direction aligned to heat sources in engineering vehicles, EV chargers, or control cabinets for maximum cooling efficiency.
Maximize Air Circulation – Even with ultra-thin design, leave sufficient clearance around the fan to ensure unobstructed airflow in tight vehicle compartments or compact enclosures.
Vibration-Proof Mounting – Use shock-absorbing brackets or pads to maintain stable performance in mobile machinery and construction vehicles.
Electrical Compatibility – Verify the rated voltage and power to prevent overloading and to extend the fan’s service life in industrial and EV applications.
Environmental Protection – For outdoor or dusty sites like charging stations or construction sites, consider protective covers or filters to prevent debris accumulation.
Routine Performance Check – Regularly inspect airflow, noise, and motor heating to maintain reliable cooling for long-duration and high-duty-cycle applications.
Global Ready Design – The fan is suitable for diverse climates, including North America, Europe, Southeast Asia, and the Middle East, ensuring stable performance in demanding environments.
Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.
All fans undergo 100% testing before shipment, with customization and technical support available.
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
1. What industries benefit most from this slim brushed fan?
Widely used in engineering vehicles, commercial buses, EV charging stations, industrial control cabinets, and compact machinery, offering versatile and efficient cooling.
2. Can this fan operate reliably in mobile equipment?
Yes. Designed for construction vehicles and commercial buses, it maintains stable performance under vibration, dust, and high temperatures.
3. Is it suitable for continuous operation in charging stations?
Absolutely. The brushed motor supports long-duration use, keeping EV charging modules and electronic cabinets cool even in high-duty cycles.
4. How does this fan help reduce maintenance and downtime?
By providing consistent thermal management, it protects sensitive electronics and batteries, minimizing overheating risks and system failures.
5. Does this fan perform well in global applications?
Yes. Engineered for North America, Europe, Southeast Asia, and the Middle East, it delivers reliable cooling in diverse climates and environments.
