SLT0912C-W10
Sunlight
| Voltage: | |
|---|---|
| Quantity: | |
| Noise | ≤70dB(A) |
| Waterproof | IP63/IP68 |
| Weight | 1.4KG |
| Operating supply voltage rang | 12V |
| Operating working temperature range | -40°C - 85°C |
| Storage temperature range | -40°C - 100°C |
| Life time | up to 2400 hours depending on mission profile |
Flexible Blow / Suction Installation: Support both blowing and suction directions to match your system layout.
High Cooling Efficiency: Optimized blade geometry enhances airflow and heat dissipation.
Sealed and Durable Design: IP63/IP68 protection against dust and strong water jets.
Low Noise Operation: Balanced impeller design keeps noise ≤ 70 dB(A).
Wide Temperature Range: Works reliably between –40 °C and +85 °C.
Long Service Life: Up to ~2400 hours under normal rated conditions.
This fan is ideal for use in:
Radiator cooling systems for trucks, buses, and specialty vehicles
Construction machinery and excavators
Agricultural machinery (e.g. manure spreaders, harvesters)
Refrigerated transport vehicles
Snow removal / winter equipment
Forestry and engineering machinery
Sample Lead Time: 14days
Mass Production: 21days
MOQ: 2
Customization: Voltage, control mode, wiring, housing treatment available
Contact Us:
Sunny Li: +86-18806140118 / sunny@sunlightmotor.com
Alisa Chen: +86-18806140198 / sales3@czsunlight.com
Frances Zhang: +86-18806140168/ sales1@czsunlight.com
Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com
Q1: Is this fan reversible between blow and suction setups?
A1: Yes. By reversing the polarity of the power input, the fan can operate in blowing or suction mode, providing installation flexibility.
Q2: What is the typical current draw at 12V?
A2: The current draw is generally around 6.5–7 A under standard conditions, but actual current may vary slightly based on airflow resistance and ambient temperature.
Q3: Can this fan be used in wet or dusty environments?
A3: Definitely. With its IP63/IP68 protective rating, the fan is sealed against dust ingress and water jets, making it suitable for outdoor and harsh conditions.
Q4: What is the standard cable length and can it be customized?
A4: Standard cable length is typically 300 mm. We can customize cable length, connectors, or terminal types based on your system requirements.
Q5: Can you provide performance curves or technical test data?
A5: Yes, upon request we can share airflow vs. pressure curves, efficiency data, and test reports to assist your selection and system design.
