SLT-1124X-W7 280mm (11Inch) 24V 170W Brushed Cooling Fan - Sunlight Motor

Introducing Sunlight Motor's SLT-1124X-W7 — a 280mm (11Inch) 24V 170W brushed cooling fan for efficient heat management.
It delivers ≥1800m³/h airflow at 2800±200rpm, with current ≤7A and noise ≤70dB(A) for powerful yet quiet cooling.
Boasting IP63/ IP68 protection and a -40~+85℃ operating range, it adapts to harsh environments without component aging.
Compliant with QC/T 708-2004/417-2001 standards, its clear red/black wiring ensures easy, error-free installation.
The 280mm universal size seamlessly integrates with diverse equipment setups, meeting reliable cooling needs.

  • SLT-1124X-W7

  • Sunlight

Voltage:
24V
Availability:
Quantity:
Inquire Add to Basket

Specification of SLT-1124X-W7 280mm (11Inch) 24V 170W Brushed Fan

Test Voltage 24VDC
Load Current ≤7A
Load Speed 2800 ±200 rpm
Static Pressure 0Pa
Air Volume ≤2000 m³/h
Noise ≤70db(A)
Vibration ≤100mg
Ambient temperature range
40 °C to +85 °C
Waterproof IP63/lP68


Drawing of SLT-1124X-W7 280mm (11Inch) 24V 170W Brushed Fan

SLT-1124X-W7外形图

Real photo of SLT-1124X-W7

16-2-3


Advantages of SLT-1124X-W7 280mm (11Inch) 24V 170W Brushed Fan


  • High airflow output: ≥1800 m³/h at 0 Pa (rapidly cools equipment, avoids overheating downtime)

  • Reliable waterproof design: IP63/IP68 rating (resists dust/moisture, protects internal components in complex environments)

  • Long service life: Up to 8,000 operating hours (reduces replacement frequency and maintenance costs)

  • Wide operating temperature: –40 °C to +85 °C (adapts to extreme industrial/outdoor temperature fluctuations)

  • Stable current draw: ≤7 A at 0 Pa load (24V 170W efficient operation, prevents circuit overload)

  • Compact 280 mm (11″) diameter (fits mainstream radiators/equipment enclosures, solves space-constrained installation)

  • Push (blower) configuration: Fits front-mount cooling systems (flexible integration with diverse setups)

  • Certifications included: Compliant with QC/T 708-2004/417-2001/29106 (meets automotive/industrial standards)

  • Customizable options available: Mounting & connectors (adapts to specific equipment requirements, lowers adaptation costs)


Application of SLT-1124X-W7 280mm (11Inch) 24V 170W Brushed Fan


Suitable for use in

  • Trucks, trailers, and refrigeration units

  • Condensers, radiators, heat exchangers

  • Construction & utility vehicles

  • Buses, ambulances, engineering vehicles

  • Agricultural, mining, forestry machinery

  • New energy vehicles, charging station thermal managemer



图片5图4应用图

Installation & Usage Tips


  • Mount Flat & Securely: Use a flat mounting surface with proper torque. Avoid frame deformation—ensure stable ≥1800m³/h airflow output and prevent vibration from exceeding 100mg, avoiding performance degradation.

  • Maintain Clear Airflow: Do not obstruct inlet/outlet paths; allow free airflow—prevent equipment overheating shutdown and ensure consistent cooling matching 2800±200rpm rated speed.

  • Wiring Polarity: Connect correct polarity (positive-negative matching). Reverse polarity risks driver damage (red/black wires clearly marked, compliant with QC/T 417-2001 standards, minimizing misconnection errors).

  • Stable Power Supply: Keep 24V rated voltage for stable operation; ensure current ≤7A and power ripple ≤1%—avoid speed fluctuations that affect cooling efficiency and protect circuit safety.

  • Use Clean Environments: IP63 rated, avoid corrosive liquids/strong chemicals; -40~+85℃ operating temp—protect ≥125℃ heat-resistant irradiated wires from aging, cracking or melting in harsh conditions.

  • Routine Checks: Periodically inspect wiring/connections for loosening or damage—prevent fan failure caused by loose fasteners, maintaining compliance with QC/T 708-2004 standards.

  • Storage Conditions: Store dry at -40~+85℃ to preserve insulation and materials—ensure harness and components retain performance for future use, avoiding storage-related failures.

  • Control & Regulation: Adopt reliable wiring control compliant with QC/T 29106 standards—seamlessly integrate with equipment systems without complex additional devices, reducing integration costs.


About us

Since 1990, Sunlight has specialized in manufacturing high-performance brushless fans and blowers. Certified with ISO9001 and IATF16949, our products meet CE, RoHS, and EMC standards. Widely applied in automotive, machinery, refrigeration and energy industries. Sunlight is committed to delivering quality, innovation, and reliable cooling solutions.

All fans undergo 100% testing before shipment, with customization and technical support available.


Certifications

5图片31637图片1


Exhibition

DELIVERYEXHIBITION2WAREHOUSE

Brushless Axial Fans - czsunlight.com (15)Brushless Axial Fans - czsunlight.com (16)Brushless Axial Fans - czsunlight.com (30)


Test Experiment

132510867


Ordering Information

Sample Lead Time: 14days

Mass Production: 21days

MOQ: 2

Customization: Voltage, control mode, wiring, housing treatment available

Contact Us:

Sunny Li: +86-18806140118 / sunny@sunlightmotor.com

Alisa Chen: +86-18806140198 / sales3@czsunlight.com

Frances Zhang: +86-18806140168/ sales1@czsunlight.com

Vicky Li: +86-18806140098/ sunlight@sunlightmotor.com


FAQ

1. Q: What core specs does the SLT-1124X-W7 have, and can it meet my equipment’s cooling demands?

A: It’s a 24V 280mm (11Inch) brushed cooling fan with ≥1800m³/h airflow, 2800±200rpm speed, and ≤7A current—perfect for resolving overheating issues in high-load equipment.

2. Q: Can the SLT-1124X-W7 work reliably in harsh industrial or outdoor environments?

A: Yes. With IP63 protection rating and -40~+85℃ operating temperature range, it resists dust/moisture, and its ≥125℃ heat-resistant wires avoid aging/deformation in extreme conditions.

3. Q: How to avoid wiring mistakes and ensure secure installation for the SLT-1124X-W7?

A: Follow the clear red/black wire polarity marking (compliant with QC/T 417-2001) to prevent misconnection; mount on a flat surface with proper torque to avoid loose fasteners or frame deformation.

4. Q: Does the SLT-1124X-W7 comply with relevant industry standards for professional use?

A: It meets key standards including QC/T 708-2004 (automotive HVAC blowers), QC/T 29106 (low-voltage wiring harnesses), and QC/T 417-2001 (connectors)—ensuring compatibility and reliability.

5. Q: What are the noise and vibration levels of the SLT-1124X-W7, and will it interfere with my equipment?

A: It operates with noise ≤76dB(A) and vibration ≤100mg, maintaining quiet and stable performance while delivering powerful cooling, with no disruption to your setup.
